How Much Does Drill Pipe Weigh?

The weight of drill pipe depends on its size, material (steel grade), and length. Drill pipe is typically made of steel and is designed to withstand the high-pressure conditions found in drilling operations. Here are some general guidelines to help you understand typical weight ranges.

Drill pipe weight ranges:
Outer diameter (OD): Drill pipe typically has a diameter between 2 3/8 inches (60.3 mm) and 6 5/8 inches (168.3 mm).

Weight per length: Depending on the specific design and material, drill pipe typically weighs between 8 and 50 pounds per foot (12 to 74 kg per meter).

Example weight ranges:
2" 3/8" drill pipe typically weighs approximately 8-12 pounds per foot (12-18 kg per meter).
3" 1/2" drill pipe typically weighs approximately 14-18 pounds per foot (21-27 kg per meter).
5" drill pipe typically weighs approximately 22-30 pounds per foot (33-45 kilograms per meter).
6" 5/8" drill pipe typically weighs approximately 30-50 pounds per foot (45-74 kilograms per meter).

Factors affecting drill pipe weight:

- Size (outer diameter and wall thickness):
This is the most decisive factor. The larger the outer diameter and the thicker the wall, the heavier the drill pipe.

- Material:
Depending on the design, high-strength steel or exotic materials may result in heavier or lighter drill pipe; for example, alloy steel is heavier than standard steel.

- Length:
Standard lengths for individual drill pipes are typically approximately 9.5 meters (31 feet) or approximately 13 meters (43 feet), with weight increasing linearly with length. The total length of all drill pipe must be considered when calculating total weight.

- Coating and Threading:
Additional coatings or threads may also cause slight weight variations.

For specific applications, weight can be customized based on operational requirements, such as drilling depth and required strength. Grooving increases weight compared to flat drill pipe (for example, Φ89mm grooved drill pipe is approximately 40% heavier than flat drill pipe).

How do you calculate the total weight of a drill string?

A drill string for a well several thousand meters deep is made up of hundreds of connected drill pipes. Its total weight is staggering.

Calculation formula:
Total drill string weight = Weight of a single drill pipe × Total number of drill pipes

For example:
A 3,000-meter-deep well uses 5-inch, standard-weight drill pipe (approximately 280 kg per pipe).

A single drill pipe is approximately 9.5 meters long.

The number of drill pipes required is ≈ 3,000 meters / 9.5 meters per pipe, ≈ 316 pipes.
The total weight of the drill string is ≈ 280 kg per pipe × 316 pipes, ≈ 88,480 kg, ≈ 88.5 tons.

This doesn't include the weight of the even heavier bottom hole assembly (BHA), including drill collars (used to pressurize the drill bit), stabilizers, and joints. A BHA can weigh anywhere from tens to hundreds of tons.

Thus, the entire drill string for a deep well can easily weigh over 100 tons, sometimes even hundreds of tons. This immense weight is ultimately supported and managed by the traveling hoist system (crown block, traveling block, hook) and the rig's winch atop the derrick.

If you need the exact weight of a specific drill pipe specification, the best way is to consult the manufacturer's drill pipe weight specification chart, which clearly lists the theoretical weight.
